These LED area lights have a documented 70 W rating, fixed 4000 K colour temperature and Type IV distribution, with 9,310 lm output for the selected 120–277 V AC configuration. Compare the mounting and control choices for your outdoor area or car-park lighting layout.
| Exact documented configuration | RDAL0204 configuration codes shown in options below |
|---|---|
| Documented electrical input | 70 W |
| Documented AC input | 120–277 V AC |
| Fixed colour temperature | 4000 K |
| Distribution class | Type IV |
| Selected lumen output | 9310 lm |
| Documented housing/lens | Die-cast aluminium housing and polycarbonate optical lens |
| Documented finish | Dark bronze |
| Option: Slip-fitter mount / No photocell code;cap unconfirmed | SKU RDAL02040704KDNSFL4D |
| Option: Slip-fitter mount / Photocell option | SKU RDAL02040704KDPSFL4D |
| Option: Extrusion arm / No photocell code;cap unconfirmed | SKU RDAL02040704KDNEXL4D |
| Option: Extrusion arm / Photocell option | SKU RDAL02040704KDPEXL4D |
| Option: Trunnion mount / No photocell code;cap unconfirmed | SKU RDAL02040704KDNTRL4D |
| Option: Trunnion mount / Photocell option | SKU RDAL02040704KDPTRL4D |
| Option: Wall mount / No photocell code;cap unconfirmed | SKU RDAL02040704KDNWML4D |
| Option: Wall mount / Photocell option | SKU RDAL02040704KDPWML4D |
The complete delivered package is unconfirmed. Confirm the selected luminaire,driver,mounting hardware,control equipment and quantities. Optional mounting and control accessories are not established as included.
The complete delivered contents are unconfirmed. Check the light,driver,bracket,photocell,receptacle,cap,adapters,fixings and quantities for the selected choice. A pictured mount does not establish every included part.
No. Confirm the actual driver,frequency where unconfirmed,wiring and UK conformity documents for the site. Have a qualified installer assess the mounting structure and electrical supply.
N identifies a choice without photocell. It does not establish a supplied cap or receptacle. Confirm the exact control hardware and package for the selected option; photocell choices are separate.
Follow the supplied rating labels and instructions. Confirm electrical connections,driver controls,permitted tilt,exposure,fixings and structural loading before installation. Distribution classes and wattages do not establish universal pole fit,HID replacement equivalence or guaranteed field coverage.
Browse LED outdoor area lights
Related listings to browse: LED area lights - 150 W, 4000 K, Type V, 20500 lm and LED area lights - RKAL03 Catalogue Mounting Choices. These browsing links do not imply compatibility or direct replacement.
Delivery
Tracked delivery in 3–7 working days. Delivery costs are shown at checkout before you pay, and you will receive tracking details as soon as your order ships.
Returns
Changed your mind? You can return items within 14 days of delivery. If anything arrives damaged or faulty, email ukcustomerservice@lumimuse.com with a photo and we will arrange a replacement or refund.
Specifications apply to the selected option and the components listed below.
Slip Fitter / With Shorting Cap · SKU: RDAL02040704KDNSFL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDNSFL4D luminaire with slipfitter mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Slip Fitter / With Dusk to Dawn Photocell +$15 · SKU: RDAL02040704KDPSFL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDPSFL4D luminaire with slipfitter mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Extrusion Arm / Pole Mount (square/round) / With Shorting Cap · SKU: RDAL02040704KDNEXL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDNEXL4D luminaire with extrusion arm mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Extrusion Arm / Pole Mount (square/round) / With Dusk to Dawn Photocell +$15 · SKU: RDAL02040704KDPEXL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDPEXL4D luminaire with extrusion arm mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Yoke / Trunnion Mount / With Shorting Cap · SKU: RDAL02040704KDNTRL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDNTRL4D luminaire with yoke/trunnion mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Yoke / Trunnion Mount / With Dusk to Dawn Photocell +$15 · SKU: RDAL02040704KDPTRL4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDPTRL4D luminaire with yoke/trunnion mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Wall Mount / With Shorting Cap · SKU: RDAL02040704KDNWML4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDNWML4D luminaire with wall mount mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Wall Mount / With Dusk to Dawn Photocell +$15 · SKU: RDAL02040704KDPWML4D
| Input voltage (V) | 120.0–277.0 |
|---|---|
| Supply type | AC |
| Rated power (W) | 70.0 |
| Luminous flux (lm) | 9310 |
| Colour temperature (K) | 4000 |
One RDAL02040704KDPWML4D luminaire with wall mount mounting and Type IV distribution. Ratings follow the manufacturer's January 2022 specification. Confirm the supplied revision, photocell or cap contents, dimming connection and UK installation suitability.
Specifications for this option are unavailable. Please confirm the required details before ordering.
